1. About Us / Our Products & Services

T’sys Industrial Controls Inc., established in 2002 is a corporate affiliate of Total Power Box Solution Inc. and one of the country’s leading fabrication & manufacturing company of electrical equipment.

Our combined core competency is in fully automated design, production, retrofit & installation of electrical& power control system, High Voltage Switchgear (HVSG), Medium Voltage Switchgear (MVSG), Low Voltage Switchgear (LVSG), Panelboards, Busduct / Busway Feeder System.

Our team of duly certified electrical engineers have the skills & full capability to customize and prefabricate any and all types of electrical design requirements for commercial & industrial applications using the most advanced three dimensional (3D) design system fully integrated with our CAD and CAM mechatronics in the country comparable to foreign & global electrical design systems.

Our Products

Molded Case Circuit Breakers (Himel brand)

Basic Technical Data

Rated Insulation Voltage Ui, AC 800V
Rated Impulse Withstand Voltage Uimp, 8KV
Rated Working Voltage Ue, AC 400V
Rated Operational Frequency, 50Hz
Utilization Category, A

Advantages

Convenient and flexible setting parameters.
Perfect industrial design.
Reliable quality.

Download product brochure

Manual Starter (Himel brand)

Functions

Equivalent to average 3 pole circuit breaker and thermal overload relay combination.
It can directly towing load in some low operation frequency occasions instead of contactor.

Advantages

Gives the most professional, most comprehensive motor control and protection.
Perfect industrial design.
Easy installation, firm connection.

Download product brochure

HDB6s/HDB9 18mm Miniature Circuit Breaker

Functions

Protection of circuits against overload currents.
Protection of circuits against short-circuit currents.
Control.
Isolation.

Advantages

High breaking capacity up to 10kA.
“Class 3” current energy limiting capacity.
High quality raw material with ambient temperature rating of -30℃ ~ 70℃.
Thermoplastic material shell, impact resistance, fire retardancy.
With “QUICK CLOSED” technology:
- Electrical Durability: 10000 times
- Mechanical Durability: 20000 times

Download product brochure

Fuji Electric - AQUA

Basic Technical Data

WIDE VARIATION IN MODEL CAPACITY.
STANDARD TYPE (EMC BUILT IN TYPE).
- 0.75 TO 710KW (PROTECTIVE STRUCTURE IP21 OR IP55 CAN BE SELECTED BETWEEN 0.75 AND 90 KW.
DCR BUILT IN TYPE + EMC FILTER BUILT IN TYPE.
- 0.75 TO 710KW (PROTECTIVE STRUCTURE IP21 OR IP55 CAN BE SELECTED BETWEEN 0.75 AND 90 KW.
3 ANALOG INPUTS.
9 PROGRAMMABLE DIGITAL INPUT.
BUILT IN SAFE TORQUE OFF (STO).
2 DRY CONTACT RELAY OUTPUT (PROGRAMMABLE).
4 TRANSISTOR OUTPUT (PROGRAMMABLE).
2 ANALOG OUTPUT (PROGRAMMABLE).
RS 485 COM PORT (BACNET MSTP, MODBUS RTU, METASYS N2) STANDARD EQUIPMENT.
OPTION DEVICE: LONWORKS, ETHERNET, PROFIBUS, DEVICENET CANOPEN, CC-LINK

Advantages/Features

OPTIMAL CONTROL WITH ENERGY SAVING FUNCTION.
DEDICATED PUMP CONTROL FUNCTION PROVIDED AS STANDARD.
SLIM BODY.
FUNCTION SUITABLE FOR HVAC USE.
STAND ALONE.
SEMI F47 VOLTAGE SAG IMMUNITY COMPLIANCE CERTIFIED.

Download product brochure

Fuji Electric - ACE

Basic Technical Data

STANDARD TYPE MODEL (BASIC TYPE)
BUILT IN BREAK CHOPPER 0.2KW TO 37KW, 45KW TO 590KW (OPTION).
SINGLE PHASE MODEL SPECIFICATIONS. 0.1KW TO 2.2KW 200V CLASS SERIES (BASIC TYPE).
EMC FILTER BUILT IN TYPE SPECIFICATION FOR 3PH 200V 400V CLASS SERIES.
EMC FILTER BUILT IN TYPE SPECIFICATION FOR SINGLE PHASE 200V CLASS SERIES.
DC REACTOR OPTION.
2 ANALOG INPUTS.
7 PROGRAMMABLE DIGITAL INPUT.
BUILT IN SAFE TORQUE OFF (STO).
1 DRY CONTACT RELAY OUTPUT (PROGRAMMABLE).
2 TRANSISTOR OUTPUT (PROGRAMMABLE).
2 ANALOG OUTPUT (PROGRAMMABLE).
RS 485 COM PORT (MODBUS RTU) STANDARD EQUIPMENT.
OPTION DEVICE: DEVICENET, CANOPEN, CC-LINK, PROFIBUS-DP, ETHERNET/IP, PROFINET-RT

Advantages

CUSTOMIZABLE LOGIC FUNCTIONS (Maximum of 200 steps including both digital and analog operation function).
WIDE VARIETY OF FUNCTIONS AS STANDARD FEATURES Sensor less dynamic torque vector control, Motor vector control with PG (with optional card), Synchronous motor with sensor less vector control, 2-channel on-board RS485 communications port, Standard CAN open compatibility, Removable keypad device, Removable control terminal block board.
SUPERIOR FLEXIBILITY Frenic-Ace has readily available interface cards and various types of fieldbus / network to maximize its flexibility.
MULTI FUNCTION KEYPAD (OPTION) Multi-function keypad with LCD display: Enhanced HMI functionality Keypad with USB Port: Connect to a computer for more efficient operation (set -up, troubleshooting, maintenance, etc.)
10 YEARS LIFETIME DESIGN.

Download product brochure

Fuji Electric - HVAC

Basic Technical Data

WIDE VARIATION IN MODEL CAPACITY.
STANDARD TYPE (EMC BUILT IN TYPE)
0.75 TO 710KW (PROTECTIVE STRUCTURE IP21 OR IP55 CAN BE SELECTED BETWEEN 0.75 AND 90 KW.
DCR BUILT IN TYPE + EMC FILTER BUILT IN TYPE.
0.75 TO 710KW (PROTECTIVE STRUCTURE IP21 OR IP55 CAN BE SELECTED BETWEEN 0.75 AND 90 KW.
3 ANALOG INPUTS.
9 PROGRAMMABLE DIGITAL INPUT.
BUILT IN SAFE TORQUE OFF (STO).
2 DRY CONTACT RELAY OUTPUT (PROGRAMMABLE).
4 TRANSISTOR OUTPUT (PROGRAMMABLE).
2 ANALOG OUTPUT (PROGRAMMABLE).
RS 485 COM PORT (BACNET MSTP, MODBUS RTU, METASYS N2) STANDARD EQUIPMENT.
OPTION DEVICE: LONWORKS, ETHERNET, PROFIBUS, DEVICENET CANOPEN, CC-LINK

Advantages/Features

OPTIMAL CONTROL WITH ENERGY SAVING FUNCTION.
DEDICATED PUMP CONTROL FUNCTION PROVIDED AS STANDARD.
SLIM BODY.
FUNCTION SUITABLE FOR HVAC USE.
STAND ALONE.
SEMI F47 VOLTAGE SAG IMMUNITY COMPLIANCE CERTIFIED.

Download product brochure

Fuji Electric - MEGA

Basic Technical Data

STANDARD SPECIFICATIONS (BASIC TYPE).
HD (HIGH DUTY) HEAVY LOAD
LD (LOW DUTY) LIGHT LOAD
SINGLE PHASE MODEL SPECIFICATIONS. 0.1KW TO 2.2KW 200V CLASS SERIES (BASIC TYPE).
EMC FILTER BUILT IN TYPE SPECIFICATION FOR 3PH 200V 400V CLASS SERIES.
EMC FILTER BUILT IN TYPE SPECIFICATION FOR SINGLE PHASE 200V CLASS SERIES.
DC REACTOR OPTION.
2 ANALOG INPUTS.
7 PROGRAMMABLE DIGITAL INPUT.
BUILT IN SAFE TORQUE OFF (STO).
1 DRY CONTACT RELAY OUTPUT (PROGRAMMABLE).
2 TRANSISTOR OUTPUT (PROGRAMMABLE).
2 ANALOG OUTPUT (PROGRAMMABLE).
RS 485 COM PORT (MODBUS RTU) STANDARD EQUIPMENT.
OPTION DEVICE: DEVICENET, CANOPEN, CC-LINK, PROFIBUS-DP, ETHERNET/IP, PROFINET-RT

Advantages

CUSTOMIZABLE LOGIC FUNCTIONS (Maximum of 200 steps including both digital and analog operation function).
WIDE VARIETY OF FUNCTIONS AS STANDARD FEATURES Sensor less dynamic torque vector control, Motor vector control with PG (with optional card), Synchronous motor with sensor less vector control, 2-channel on-board RS485 communications port, Standard CAN open compatibility, Removable keypad device, Removable control terminal block board.
SUPERIOR FLEXIBILITY Frenic-Ace has readily available interface cards and various types of fieldbus / network to maximize its flexibility.
MULTI FUNCTION KEYPAD (OPTION) Multi-function keypad with LCD display: Enhanced HMI functionality Keypad with USB Port: Connect to a computer for more efficient operation (set -up, troubleshooting, maintenance, etc.)
10 YEARS LIFETIME DESIGN.
